N Type Male to TNC Male, Flexible .141‘’_SS402 Cable, 12GHz

N Type Male to TNC Male, Flexible .141‘’_SS402 Cable, 12GHz

The Flexible .141''(SS402) coaxial cables are perfect for interconnection of coaxial components or sub-systems connection. The cable construction includes a silver-plated copper-clad steel center conductor, low loss PTFE, and two silver plated copper shield braiding, which minimizes signal leakage and at the same time flexible for easy bend. Connectors have passivated stainless-steel coupling nut over a gold plated connector body that make the connection more reliable. The Flexible .141'' Series Flexible cables are available in variety of length to meet your requirements. ZOMWAVE provide N Type Male to TNC Male, Flexible .141‘’_SS402 Cable, 12GHz high perfomance and low price.

Standard Lengths :

12in 24in 36in 48in

P/N:NCPSTNPS-T141-12IN-01 Quantity Unit Price 01~09 US$23.60 10~49 US$22.69 50~99 US$21.85 100~199 US$20.34 200+ Call Us

P/N:NCPSTNPS-T141-24IN-01 Quantity Unit Price 01~09 US$26.55 10~49 US$25.53 50~99 US$24.58 100~199 US$22.89 200+ Call Us

P/N:NCPSTNPS-T141-36IN-01 Quantity Unit Price 01~09 US$29.50 10~49 US$28.36 50~99 US$27.31 100~199 US$25.43 200+ Call Us

P/N:NCPSTNPS-T141-48IN-01 Quantity Unit Price 01~09 US$32.45 10~49 US$31.20 50~99 US$30.04 100~199 US$27.97 200+ Call Us

ORDER NOW

*More quantity request or best price, please sent the RFQ to zomwave sales

Pictures

Specifications

n male cable, type n cable assembly, tnc male cable, ss402

n male cable, type n cable assembly, tnc male cable, ss402, coaxial cable supplier

Q1. What is your delivery time?

A1). We promise within 5 days ship out for the standard products less than 200 pcs.

A2). Customized products would be 2~3 weeks lead time.

Q2. Which shipping way is available and how to track?

A1). By international Express like FedEx, DHL, TNT, UPS, normally door to door in 5~7 days.

A2). Tracking No. will be sent after goods ship out.

Q3. Do your price include freight cost and custom duty?

A1). Price do NOT include the freight cost and import duty.

A2). We can quote you the detail freight cost by our forwarder agent.

Q4. Which payment way is workable?

A1). We accept Wire Transfer (T/T) and PayPal payments (order value less than USD$500).

A2). Payment in advance for new clients.

Q5. What is the MOQ of your products?

A1). No MOQ request for standard products (include customized length cable) on our website.

A2). Other customized products we request 500 pcs MOQ (Minimum Order Quantity).

Q6. Could you supply the sample for me to test first?

A1). We are honored to offer you samples. New clients are expected to pay the sample fee.

A2). Sample fee can be refunded in your mass production order (total quantity up to 1000 pcs).

Configuration
Connector Series 1	Type N
Connector Gender 1	Male
Connector Angle 1	Straight
Connector Mount Method1	None
Body Materials and Plating 1	Brass, Nickel Plated
Connector Series 2	TNC
Connector Gender 2	Male
Connector Angle 2	Straight
Connector Mount Method 2	None
Body Materials and Plating 2	Brass, Nickel Plated
Cable Type	Flexible .086''/ SS402
Electric Specifications
Impedance	50ohm
Frequency Range(From DC)	12GHz
VSWR	≤1.25:1 (DC 0~12GHz)
Insertion Loss	Depends on cable length
Voltage Rating	335 V(rms)
Dielectric Withstanding Voltage	500 V
Insulation Resistance	≥500 Mohm
Mechanical Characteristics
Mating Cycles	≥ 500 cycles
Mating Torque	30 in - lbs
Environmental Characteristics （RoHS Complliant)
Temperature Rating	-40°C ~ +85°C
Corrosion (Salt Spray)	MIL-STD-202, Method 101, Condition B
Vibration	MIL-STD-202, Method 204, Condition D, 20 Gs
Shock	MIL-STD-202, Method 213, Condition I, 100 Gs
Thermal Shock	MIL-STD-202, Method 107. Cond. B, -40°C to +85°C
Moisture Resistance	MIL-STD-202, Method 106, Less Step 7B
Barometric Pressure (Altitude)	MIL-STD-202, Method 105, Condition C, 70k Ft.
Cable Specification
Center Conductor	Silver plated copper
Dielectric	Low Density PTFE
Jacket	FEP
Jacket Diameter(mm)	4.1±0.05
Min. Bending Radius(mm)	10
Shielding Effect(dB)	>90
Weight(kg/km)	18(Reference)
Cable Attenuation ＠ 20℃ and Sea Level, Power
Frequency (GHz)	Attenuation(dB/m)
0.5	0.25
1	0.37
2	0.56
3	0.71
5	0.96
6	1.06
10	1.44
18	2.02
